TEXAS INSTRUMENTS SN74LVC1G123YZPR 芯片, 多谐振荡器, MONO, 18.5NS, DSBGA-8
单稳态多谐振荡器 18.5 ns 8-DSBGA,8-WCSP(1.9x0.9)
得捷:
IC MULTIVIBRATOR 18.5NS 8DSBGA
立创商城:
SN74LVC1G123YZPR
德州仪器TI:
Single retriggerable monostable multivibrator with Schmitt-trigger inputs
贸泽:
Monostable Multivibrator SNGL Retriggerable Mono Multivibrator
e络盟:
TEXAS INSTRUMENTS SN74LVC1G123YZPR 芯片, 多谐振荡器, MONO, 18.5NS, DSBGA-8
艾睿:
Think of Texas Instruments&s; SN74LVC1G123YZPR monostable multivibrator the next time you need to be alerted when a chosen condition is met within your project. This monostable multivibrator has an operating temperature range of -40 °C to 85 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This device has a typical operating supply voltage of 1.8|2.5|3.3|5 V. Its minimum operating supply voltage of 1.65 V, while its maximum is 5.5 V.
安富利:
Monostable Multivibrator Single 8-Pin DSBGA T/R
Chip1Stop:
Monostable Multivibrator Single -40C 85C 8-Pin DSBGA T/R
Verical:
Monostable Multivibrator Single-Element -40C 85C 8-Pin DSBGA T/R
Newark:
MULTIVIBRATOR, MONO, 18.5NS, DSBGA-8
Win Source:
Monostable Multivibrator 18.5ns 8-DSBGA, 8-WCSP 1.9x0.9
DeviceMart:
IC SNGL RETRIG MULTIVIB 8-DSBGA
电源电压DC 1.65V min
针脚数 8
位数 1
传送延迟时间 8.20 ns
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 1.65V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 1.65 V
安装方式 Surface Mount
引脚数 8
封装 DSBGA-8
长度 1.9 mm
宽度 0.9 mm
高度 0.3 mm
封装 DSBGA-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
