SRR1280-220M

SRR1280 系列磁性屏蔽线绕电感器Bourns SRR1280 系列贴片屏蔽式功率电感器为薄型，仅 7.5mm。 应用包括直流/直流转换器和电源的输入/输出，适用于：便携式通信设备；摄像机；液晶电视；汽车收音机高电流额定值 特别适合高频率 ### Bourns 非标准表面安装电感器（扼流圈）

SRR1280 系列磁性屏蔽线绕器

Bourns SRR1280 系列贴片屏蔽式功率电感器为薄型，仅 7.5mm。 应用包括直流/直流转换器和电源的输入/输出，适用于：便携式通信设备；摄像机；液晶电视；汽车收音机

高电流额定值

特别适合高频率

得捷:
FIXED IND 22UH 4.3A 38.6MOHM SMD

欧时:
Bourns SRR1280 系列 屏蔽 铁氧体芯材 22 μH 绕线贴片电感器 SRR1280-220M, ±20%容差, 4.3A Idc Q:20

立创商城:
22uH ±20% 4.3A 38.6mΩ

e络盟:
电感, 屏蔽, 22UH, 4.1A, SMD, 全

艾睿:
An ideal space-saving electronic component is this power SRR1280-220M surface mount inductor from Bourns. This SMD inductor has an operating temperature range of -40 °C to 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This product is 12.8 mm long, 8 mm tall and 12.8 mm deep. It has a tolerance of 20%. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 11MTyp Hz. This device utilizes wirewound technology. It has an inductance of 22u H. This SMD inductor has a maximum DC current of 4.3 A with a maximum resistance of 38.6m Ohm.

Allied Electronics:
Inductor; Power; Shielded; Wirewound; 22uH; 20%; 4.3A

安富利:
Ind Power Shielded Wirewound 22uH 20% 100KHz 20Q-Factor Ferrite 4.3A T/R

Chip1Stop:
Ind Power Shielded Wirewound 22uH 20% 100KHz 20Q-Factor Ferrite 4.3A T/R

Verical:
Inductor Power Shielded Wirewound 22uH 20% 100KHz 20Q-Factor Ferrite 4.3A 38.6mOhm DCR T/R

Newark:
# BOURNS  SRR1280-220M  Surface Mount Power Inductor, SRR1280 Series, 22 µH, 4.3 A, 4.1 A, Shielded, 0.0386 ohm

MASTER:
Inductor Power - Shielded - Wirewound - 12.5 x 12.5 x 7.5mm - 22 µH - 1KHz - 4.3A - 38.6m Ohm.

Online Components:
Inductor Power Shielded Wirewound 22uH 20% 100KHz 20Q-Factor Ferrite 4.3A 38.6mOhm DCR T/R

Electro Sonic:
Inductor Power - Shielded - Wirewound - 12.5 x 12.5 x 7.5mm - 22 µH - 1KHz - 4.3A - ...
