SN74AUP1G14DBVR

TEXAS INSTRUMENTS  SN74AUP1G14DBVR  非门, AUP系列, 施密特触发, 1输入, 4 mA, 800 mV至3.6V, SOT-23-5

The is a low-power single Schmitt-trigger Inverter. The device ensures very low static and dynamic power consumption across the entire VCC range of 0.8 to 3.6V, resulting in an increased battery life. This product also maintains excellent signal integrity. This device functions as an independent gate with Schmitt-trigger inputs, which allows for slow input transition and better switching-noise immunity at the input. This device is fully specified for partial-power-down applications using Ioff. The Ioff circuitry disables the outputs, preventing damaging current backflow through the device when it is powered down.

.

Low static-power consumption

.

Low dynamic-power consumption

.

Low input capacitance

.

Low noise - overshoot and undershoot

.

Ioff supports partial-power-down mode operation

.

Includes Schmitt-trigger inputs

.

Optimized for 3.3V operation

.

3.6V I/O tolerant to support mixed-mode signal operation

.

Suitable for point-to-point applications

.

Latch-up performance exceeds 100mA per JESD 78, Class II

.

ESD performance tested per JESD 22

.

Green product and no Sb/Br
