BOURNS SDE0403A-470K 表面贴装功率电感器, AEC-Q200 SDE0403A系列, 47 µH, ± 10%, 非屏蔽, 0.631 ohm, 500 mA
**Features:
**
* High Saturation Current
* Inductance Range: 1 to 68 μH
* Heating Current Up to 2.7 A
* Dimensions: 4.5 × 4 × 3.2 mm
* AEC-Q200 Qualified**
Applications:
**
* Automotive Systems: Driver Assistant, Information, Entertainment and Lighting
* DC/DC Converters
* Power Supplies
立创商城:
47uH ±10% 500mA 505mΩ
得捷:
FIXED IND 47UH 500MA 631MOHM SMD
贸泽:
Fixed Inductors 47uH 10% SMD 0403 AEC-Q200
e络盟:
# BOURNS SDE0403A-470K 表面贴装功率电感器, AEC-Q200 SDE0403A系列, 47 µH, ± 10%, 非屏蔽, 0.631 ohm, 500 mA
艾睿:
An ideal space-saving electronic component is this power SDE0403A-470K surface mount inductor from Bourns. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This product is 4.8 mm long, 3.5 mm tall and 4.3 mm deep. It has a tolerance of 10%. Its test frequency is 1M Hz, while its minimum self-resonant frequency is 16MTyp Hz. It has an inductance of 47u H. This SMD inductor has a maximum DC current of 500mA typ with a maximum resistance of 631m Ohm. This device is made with wirewound technology.
Allied Electronics:
SMD Non-Shielded Power Inductor; 47uH; 10%; SDE0403A
安富利:
Ind Power 47uH 10% 1MHz Ferrite 500mA T/R
Verical:
Inductor Power Unshielded Wirewound 47uH 10% 1MHz Ferrite 0.5A 0.631Ohm DCR Automotive T/R
Newark:
# BOURNS SDE0403A-470K Surface Mount Power Inductor, AEC-Q200 SDE0403A Series, 47 H, 10%, Unshielded, 0.631 ohm, 500 mA
额定电流 500 mA
容差 ±10 %
电感 47 µH
自谐频率 16 MHz
电感公差 ±10 %
测试频率 1 MHz
电阻DC) 0.631 Ω
工作温度Max 125 ℃
工作温度Min 40 ℃
电阻DC Max 0.631 Ω
安装方式 Surface Mount
引脚数 2
封装 SMD
长度 4.5 mm
宽度 4 mm
高度 3.5 mm
封装 SMD
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 无铅
REACH SVHC标准 No SVHC
REACH SVHC版本 2016/06/20
