SN74LVC00ADBR

四路2输入正与非门 QUADRUPLE 2-INPUT POSITIVE-NAND GATES

DESCRIPON/ORDERING INFORMATION

The SN54LVC00A quadruple 2-input positive-NAND gate is designed for 2.7-V to 3.6-V VCC operation, and the SN74LVC00A quadruple 2-input positive-NAND gate is designed for 1.65-V to 3.6-V VCC operation.

FEATURES

• Operate From 1.65 V to 3.6 V

• Specified From –40°C to 85°C, –40°C to 125°C, and –55°C to 125°C

• Inputs Accept Voltages to 5.5 V

• Max tpd of 4.3 ns at 3.3 V

• Typical VOLP Output Ground Bounce

<0.8 V at VCC= 3.3 V, TA= 25°C

• Typical VOHV Output VOH Undershoot

>2 V at VCC = 3.3 V, TA = 25°C
