低功耗双逆变器缓冲/驱动器,具有漏极开路输出 LOW-POWER DUAL INVERTER BUFFER/DRIVER WITH OPEN-DRAIN OUTPUTS
The AUP family is s premier solution to the industrys low-power needs in battery-powered portable applications. This family ensures a very low static- and dynamic-power consumption across the entire VCC range of 0.8 V to 3.6 V, resulting in increased battery life see Figure 1. This product also maintains excellent signal integrity see the very low undershoot and overshoot characteristics shown in Figure 2.
The output of the SN74AUP2G06 device is open drain and can be connected to other open-drain outputs to implement active-low wired-OR or active-high wired-AND functions.
NanoStar™ package technology is a major breakthrough in IC packaging concepts, using the die as the package.
This device is fully specified for partial-power-down applications using Ioff. The Ioff circuitry disables the outputs, preventing damaging current backflow through the device when it is powered down.
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74AUP2G06DSFR TI 德州仪器 | 当前型号 | 当前型号 |
SN74AUP2G06YFPR 德州仪器 | 完全替代 | SN74AUP2G06DSFR和SN74AUP2G06YFPR的区别 |
SN74AUP2G06DCKR 德州仪器 | 完全替代 | SN74AUP2G06DSFR和SN74AUP2G06DCKR的区别 |
SN74AUP2G06DRYR 德州仪器 | 类似代替 | SN74AUP2G06DSFR和SN74AUP2G06DRYR的区别 |
