74 ACT 系列,逻辑门,Texas Instrument### 74ACT 系列
74 ACT 系列,逻辑门,Texas Instrument
### 74ACT 系列
得捷:
IC GATE AND 4CH 2-INP 14SOIC
立创商城:
SN74ACT08DR
德州仪器TI:
4-ch, 2-input, 4.5-V to 5.5-V AND gates with TTL-compatible CMOS inputs
欧时:
Texas Instruments SN74ACT08DR 4个 2输入 AND 逻辑门, 24mA, 4.5 → 5.5 V电源, 14引脚 SOIC封装
贸泽:
Logic Gates Quad 2-Input Pos
艾睿:
Perform multiple different logical operations through the use of Texas Instruments&s; SN74ACT08DR logic gates. This gate has an operating temperature range of -40 °C to 85 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.5 V, while its maximum is 5.5 V.
安富利:
AND Gate 4-Element 2-IN CMOS 14-Pin SOIC T/R
Chip1Stop:
AND Gate 4-Element 2-IN CMOS 14-Pin SOIC T/R
Verical:
AND Gate 4-Element 2-IN CMOS 14-Pin SOIC T/R
Newark:
# TEXAS INSTRUMENTS SN74ACT08DR AND Gate, 74ACT08, 2 Input, 24 mA, 4.5 V to 5.5 V, SOIC-14
Win Source:
AND Gate IC 4 Channel 14-SOIC
DeviceMart:
IC QUAD 2-IN POS-AND GATE 14SOIC
电源电压DC 4.50V ~ 5.50V
输出接口数 1
输出电流 24 mA
电路数 4
位数 4
传送延迟时间 10.0 ns
电压波节 5.00 V
逻辑门个数 4
输出电流驱动 -1.00 mA
输入数 2
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 4.5V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 4.5 V
安装方式 Surface Mount
引脚数 14
封装 SOIC-14
长度 8.65 mm
宽度 3.91 mm
高度 1.58 mm
封装 SOIC-14
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74ACT08DR TI 德州仪器 | 当前型号 | 当前型号 |
SN74ACT08D 德州仪器 | 完全替代 | SN74ACT08DR和SN74ACT08D的区别 |
CD74ACT08M 德州仪器 | 类似代替 | SN74ACT08DR和CD74ACT08M的区别 |
SN74ACT08DRG4 德州仪器 | 类似代替 | SN74ACT08DR和SN74ACT08DRG4的区别 |
