六角施密特触发反相器 HEX SCHMITT-TRIGGER INVERTERS
反相器 IC 6 通道 施密特触发器 14-SSOP
得捷:
IC INV SCHMITT 6CH 1-IN 14SSOP
立创商城:
SN74LS14DBR
德州仪器TI:
6-ch, 4.75-V to 5.25-V bipolar inverters with Schmitt-Trigger inputs
贸泽:
Inverters Hex Schmitt-Trigger Inverters
艾睿:
Texas Instruments brings you their latest SN74LS14DBR inverting Schmitt trigger, from which you can convert an analog signal into a digital signal. With a Schmitt trigger output, this is power management at its best. This inverting Schmitt trigger has a minimum operating temperature of 0 °C and a maximum of 70 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.75 V, while its maximum is 5.25 V.
安富利:
Inverter Schmitt Trigger 6-Element Bipolar 14-Pin SSOP T/R
Chip1Stop:
Inverter Schmitt Trigger 6-Element Bipolar 14-Pin SSOP T/R
Verical:
Inverter Schmitt Trigger 6-Element Bipolar 14-Pin SSOP T/R
DeviceMart:
IC HEX INVERTER SCHM TRIG 14SSOP
Win Source:
IC HEX INVERTER SCHM TRIG 14SSOP
电源电压DC 4.75V ~ 5.25V
输出电流 8.00 mA
电路数 6
位数 6
传送延迟时间 22.0 ns
电压波节 5.00 V
逻辑门个数 6
输出电流驱动 -50.0 µA
输入数 6
工作温度Max 70 ℃
工作温度Min 0 ℃
电源电压 4.75V ~ 5.25V
电源电压Max 5.25 V
电源电压Min 4.75 V
安装方式 Surface Mount
引脚数 14
封装 SSOP-14
封装 SSOP-14
工作温度 0℃ ~ 70℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LS14DBR TI 德州仪器 | 当前型号 | 当前型号 |
SN74LS14DBRG4 德州仪器 | 完全替代 | SN74LS14DBR和SN74LS14DBRG4的区别 |
SN74LS14DBRE4 德州仪器 | 完全替代 | SN74LS14DBR和SN74LS14DBRE4的区别 |
