线路驱动器 LINE DRIVERS
或非门 IC 4 通道 - 14-SOP
得捷:
IC GATE NOR 4CH 2-INP 14SOP
立创商城:
SN74128NSR
德州仪器TI:
Single 4-input, 4.75-V to 5.25-V bipolar NOR gate
贸泽:
Logic Gates 2-Input NOR Line
艾睿:
Thanks to Texas Instruments and their SN74128NSR logic gates, you can simplify your circuit down to a fundamental level. This gate has an operating temperature range of 0 °C to 70 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.75 V, while its maximum is 5.25 V.
Chip1Stop:
NOR Gate 4-Element 2-IN Bipolar 14-Pin SOP T/R
Verical:
NOR Gate 4-Element 2-IN Bipolar 14-Pin SOP T/R
Newark:
# TEXAS INSTRUMENTS SN74128NSR NOR Line Driver, TTL12, 2 Input, 48 mA, 4.75 V to 5.25 V, SOP-14
Win Source:
NOR Gate IC 4 Channel 14-SO
电源电压DC 4.75V ~ 5.25V
输出接口数 1
输出电流 48 mA
供电电流 20.0 mA
电路数 4
位数 4
传送延迟时间 22.0 ns
电压波节 5.00 V
静态电流 33.0 mA
逻辑门个数 4
输出电流驱动 -50.0 µA
输入数 2
工作温度Max 70 ℃
工作温度Min 0 ℃
电源电压 4.75V ~ 5.25V
电源电压Max 5.25 V
电源电压Min 4.75 V
安装方式 Surface Mount
引脚数 14
封装 SOP-14
长度 10.3 mm
宽度 5.3 mm
高度 1.95 mm
封装 SOP-14
工作温度 0℃ ~ 70℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74128NSR TI 德州仪器 | 当前型号 | 当前型号 |
SN74128NSRE4 德州仪器 | 类似代替 | SN74128NSR和SN74128NSRE4的区别 |
