SDR1307-390KL

BOURNS  SDR1307-390KL  表面贴装功率电感器, SDR1307系列, 39 µH, ± 10%, 非屏蔽, 0.075 ohm, 2.9 A

39 µH 无屏蔽 绕线 器 2.9 A 75 毫欧最大 非标准

得捷:
FIXED IND 39UH 2.9A 75 MOHM SMD

欧时:
### SDR1307 系列线绕扼流圈Bourns SDR1307 系列贴片式功率电感器为薄型，仅 7mm。 应用包括直流/直流转换器和电源的输入/输出，适用于：便携式通信设备；摄像机；液晶电视；汽车收音机### Bourns 非标准表面安装电感器（扼流圈）

e络盟:
功率电感SMD, 39 µH, 2.9 A, 非屏蔽, 4.6 A, SDR1307系列, 13mm x 13mm x 7mm

艾睿:
Does your electronic circuit design require filtering, power supplies, and other similar functions? Then this power SDR1307-390KL surface mount inductor from Bourns is perfect for you! This SMD inductor has an operating temperature range of -40 °C to 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It has an inductance of 39u H. It has a tolerance of 10%. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 9M Hz. This product is 7.3 mm tall with a diameter of 13.5 mm. This SMD inductor has a maximum DC current of 2.9 A with a maximum resistance of 75m Ohm. This device utilizes wirewound technology.

Allied Electronics:
Power inductor SMD 39uH 2.9A

安富利:
Ind Power Wirewound 39uH 10% 100KHz 28Q-Factor Ferrite 2.9A T/R

Chip1Stop:
Ind Power Wirewound 39uH 10% 100KHz 28Q-Factor Ferrite 2.9A T/R

Verical:
Inductor Power Unshielded Wirewound 39uH 10% 100KHz 28Q-Factor Ferrite 2.9A 0.075Ohm DCR T/R

Newark:
# BOURNS  SDR1307-390KL  Surface Mount Power Inductor, SDR1307 Series, 39 H, 10%, Unshielded, 0.075 ohm, 2.9 A

Electro Sonic:
Inductor Power Wirewound 39uH 10% 100KHz 28Q-Factor Ferrite 2.9A 75mOhm DCR T/R
