SN74ALS1005N

与集电极开路输出十六进制反相缓冲器 HEX INVERTING BUFFERS WITH OPEN-COLLECTOR OUTPUTS

The is a Hex Inverting Buffer performs the Boolean function Y = A\\. The open-collector outputs require pull-up resistors to perform correctly. These outputs can be connected to other open-collector outputs to implement active-low wired-OR or active-high wired-AND functions. Open-collector devices are often used to generate higher VOH levels. It is characterized for operation from 0 to 70°C.

.

With open-collector outputs

.

Buffer versions of ALS05A

.

Green product and no Sb/Br
