六个反向器 14-SOIC -40 to 125
The SNx4LVC04A hex inverters contains six independent inverters designed for 2.7-V to 3.6-V VCC operation, and the SN74LVC04A hex inverter contains six independent inverters designed for 1.65-V to 3.6-V VCC operation. The SNx4LVC04A devices perform the Boolean function Y = A.
Inputs can be driven from 1.8-V or 3.3-V devices. This feature allows the use of these devices as translators in a mixed 1.8-V or 3.3-V system environment.
得捷:
IC INVERTER 6CH 1-INP 14SOIC
立创商城:
SN74LVC04ADRG3
德州仪器TI:
6-ch, 1.65-V to 3.6-V inverters
艾睿:
The SN74LVC04ADRG3 inverting Schmitt trigger, developed by Texas Instruments, is a great device for removing noise from an analog signal. This inverting Schmitt trigger has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This device has a typical operating supply voltage of 1.8|2.5|3.3 V. Its minimum operating supply voltage of 1.65 V, while its maximum is 3.6 V.
安富利:
Inverter 6-Element CMOS 14-Pin SOIC T/R
Chip1Stop:
Inverter 6-Element CMOS 14-Pin SOIC T/R
Win Source:
IC INVERTER 6CH 1-INP 14SOIC / Inverter IC 6 Channel 14-SOIC
电源电压DC 2.00V ~ 3.60V
电路数 6
位数 6
传送延迟时间 4.50 ns
电压波节 3.30 V, 2.70 V, 2.50 V
逻辑门个数 6
输出电流驱动 -1.00 mA
输入数 6
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 1.65V ~ 3.6V
电源电压Max 3.6 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 14
封装 SOIC-14
封装 SOIC-14
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LVC04ADRG3 TI 德州仪器 | 当前型号 | 当前型号 |
SN74LVC04AD 德州仪器 | 完全替代 | SN74LVC04ADRG3和SN74LVC04AD的区别 |
SN74LVC04ADRG4 德州仪器 | 完全替代 | SN74LVC04ADRG3和SN74LVC04ADRG4的区别 |
SN74LVC04ADE4 德州仪器 | 完全替代 | SN74LVC04ADRG3和SN74LVC04ADE4的区别 |
