SRR1206-122KL

BOURNS  SRR1206-122KL  表面贴装功率电感器, SRR1206系列, 1.2 mH, ± 10%, 屏蔽, 2.65 ohm, 250 mA

Inductor Power Shielded Wirewound 1.2mH 10% 1KHz 10Q-Factor Ferrite 250mA 2.65Ohm DCR T/R

得捷:
FIXED IND 1.2MH 250MA 2.65OHM SM

立创商城:
1.2mH ±10% 250mA 2.65Ω

e络盟:
功率电感SMD, 1.2 mH, 250 mA, 屏蔽, 510 mA, SRR1206系列, 12.7mm x 12.7mm x 6.5mm

艾睿:
This power SRR1206-122KL surface mount inductor from Bourns is ideal for saving valuable space on a PCB. This SMD inductor has an operating temperature range of -40 °C to 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This device utilizes wirewound technology. It has a tolerance of 10%. It has an inductance of 1.2m H. This product is 13 mm long, 6.5 mm tall and 13 mm deep. This SMD inductor has a maximum DC current of 250m A with a maximum resistance of 2.65 Ohm. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 1.5M Hz.

Verical:
Inductor Power Shielded Wirewound 1200uH 10% 1KHz 10Q-Factor Ferrite 0.25A 2.65Ohm DCR T/R

Newark:
# BOURNS  SRR1206-122KL  Surface Mount Power Inductor, SRR1206 Series, 1.2 mH, 10%, Shielded, 2.65 ohm, 250 mA

Online Components:
Inductor Power Shielded Wirewound 1.2mH 10% 1KHz 10Q-Factor Ferrite 250mA 2.65Ohm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 1.2mH 10% 1KHz 10Q-Factor Ferrite 250mA 2.65Ohm DCR T/R
