标准LED-SMD LED SMD 572nm Yellow-Green
绿色 572nm 指示 - 分立 2.1V 2-PLCC
得捷:
LED GREEN CLEAR 2PLCC SMD
贸泽:
标准LED-SMD LED SMD 572nm Yellow-Green
艾睿:
LED Uni-Color Yellow Green 2-Pin Chip 14113528Metric T/R
安富利:
LED Uni-Color Yellow Green 2-Pin PLCC T/R
Chip1Stop:
LED Uni-Color Yellow Green 2-Pin PLCC T/R
Verical:
LED Uni-Color Yellowish Green 2-Pin Chip 14113528Metric T/R
AMEYA360:
LED HI BRIGHT YW/GN 572NM 2-PLCC
正向电压 2.1 V
波长 572 nm
发光强度 224 mcd
耗散功率 189 W
测试电流 50 mA
正向电流 70 mA
正向电流Max 70 mA
工作温度Max 100 ℃
工作温度Min -40 ℃
耗散功率Max 189 mW
安装方式 Surface Mount
引脚数 2
封装 PLCC-2
长度 3.5 mm
宽度 2.8 mm
高度 2.05 mm
封装 PLCC-2
颜色 Green
工作温度 -40℃ ~ 100℃
产品生命周期 Not Recommended for New Designs
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SML-Z14M4TT86 ROHM Semiconductor 罗姆半导体 | 当前型号 | 当前型号 |
E5AN-HPRR2BMD-500 AC/DC24 欧姆龙 | 功能相似 | SML-Z14M4TT86和E5AN-HPRR2BMD-500 AC/DC24的区别 |
