SDR0603-680KL

BOURNS  SDR0603-680KL  表面贴装功率电感器, SDR0603系列, 68 µH, ± 10%, 非屏蔽, 0.72 ohm, 440 mA

SMD Power Inductors

Features

■Available in E12 series

■Small design of only 5.8 mm maximum diameter

■Low 3.9 mm profile

.

Applications

■Input/output of DC/DC converters

■Power supplies for:

  • Portable communication equipment

  • Camcorders

  • LCD TVs

  • Car radios

立创商城:
68uH ±10% 440mA 720mΩ

得捷:
FIXED IND 68UH 440MA 720MOHM SMD

e络盟:
功率电感SMD, 68 µH, 440 mA, 非屏蔽, 540 mA, SDR0603系列, 5.8mm x 5.8mm x 3.9mm

艾睿:
Is space on a PCB a limiting factor for your electronic circuit design? Then use this power SDR0603-680KL surface mount inductor from Bourns to save valuable space. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This SMD inductor has a maximum DC current of 440m A with a maximum resistance of 720m Ohm. This device is made with wirewound technology. It has an inductance of 68u H. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 12M Hz. It has a tolerance of 10%. This product is 3.9 mm tall with a diameter of 5.8 mm.

安富利:
Ind Power Wirewound 68uH 10% 1KHz 17Q-Factor Ferrite 440mA T/R

Verical:
Inductor Power Unshielded Wirewound 68uH 10% 1KHz 17Q-Factor Ferrite 0.44A 0.72Ohm DCR Automotive T/R

MASTER:
Inductor Power Wirewound 68uH 10% 1KHz 17Q-Factor Ferrite 440mA 720mOhm DCR Automotive T/R

Online Components:
Inductor Power Wirewound 68uH 10% 1KHz 17Q-Factor Ferrite 440mA 720mOhm DCR Automotive T/R

Electro Sonic:
Inductor Power Wirewound 68uH 10% 1KHz 17Q-Factor Ferrite 440mA 720mOhm DCR Automotive T/R
