SN74AHC00DG4

四路2输入正与非门 QUADRUPLE 2-INPUT POSITIVE-NAND GATES

DESCRIPON

The ’AHC00 devices perform the Boolean function Y = A • B or Y = A + B in positive logic.

FEATURES

• Operating Range 2-V to 5.5-V

• Latch-Up Performance Exceeds 250 mA Per JESD 17

• ESD Protection Exceeds JESD 22

   – 2000-V Human-Body Model A114-A

   – 200-V Machine Model A115-A

   – 1000-V Charged-Device Model C101

得捷:
IC GATE NAND 4CH 2-INP 14SOIC

艾睿:
NAND Gate 4-Element 2-IN CMOS 14-Pin SOIC Tube

Verical:
NAND Gate 4-Element 2-IN CMOS 14-Pin SOIC Tube
