ROHM Through Hole SPR-39 Series LEDsThe SPR-39 series consists of 3.1mm round LED lamps, from ROHM Semiconductor. The SPR-39 LEDs are bi-colour and have a domed top.### 可见光 LED,ROHM Semiconductor
ROHM Through Hole SPR-39 Series s
The SPR-39 series consists of 3.1mm round LED lamps, from . The SPR-39 LEDs are bi-colour and have a domed top.
### 可见光 LED,ROHM Semiconductor
得捷:
LED GREEN/RED DIFFUSED T-1 T/H
欧时:
SPR-39MVWF ROHM SPR-39 系列 红色/黄色/绿色 LED, 35 °视角, 3 引脚 3mm T-1
艾睿:
LED Bi-Color Red/Yellow Green 563nm/650nm 3-Pin T-1 Bulk
安富利:
LED Bi-Color Red/Yellow Green 563nm/650nm 3-Pin T-1 Bulk
富昌:
SPR-39 Series Green/Red Ø3.1 mm 35° Diffused 10/6.3 mcd 2.1/2 V Circular LED
Chip1Stop:
LED Bi-Color Red/Yellow Green 563nm/650nm 3-Pin T-1 Bulk
TME:
LED; 3mm; bicolour; red/yellow-green; 2.2-6.3mcd; 3.6-10mcd; 35°
Verical:
LED Bi-Color Red/Yellowish Green 563nm/650nm 3-Pin T-1 Bulk
儒卓力:
**BICOLOR 3MM RED/GREEN **
触点数 3
针脚数 3
正向电压 2 V
波长 563nm Green,650nm Red
发光强度 6.30 mcd
视角 35°
透镜样式 Diffused
峰值波长 563nm, 650nm
耗散功率 75/60 mW
测试电流 10 mA
工作温度Max 85 ℃
工作温度Min -25 ℃
安装方式 Through Hole
引脚数 3
封装 T-1
高度 5.20 mm
直径 3.10 mm
封装 T-1
颜色 Green, Red
工作温度 -25℃ ~ 85℃
外观颜色 White
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99



| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
SPR-39MVWF ROHM Semiconductor 罗姆半导体 | 当前型号 | 当前型号 |
GL3ED8 夏普 | 功能相似 | SPR-39MVWF和GL3ED8的区别 |
