SN74AHCT86PW

TEXAS INSTRUMENTS  SN74AHCT86PW  异或门, ACHT系列, 4门, 2输入, 8 mA, 4.5V至5.5V, TSSOP-14

Description

The SNx4AHCT86 devices are quadruple 2-input exclusive-OR gates. These devices perform the Boolean function Y = A × B or Y = AB + AB in positive logic.

Features

• Inputs are TTL-Voltage Compatible

• Latch-Up Performance Exceeds 250 mA Per JESD 17

• On Products Compliant to MIL-PRF-38535, All Parameters are Tested Unless Otherwise Noted. On All Other Products, Production Processing Does Not Necessarily Include Testing of All Parameters.

• ESD Protection Exceeds JESD 22

   – 2000-V Human-Body Model A114-A

   – 200-V Machine Model A115-A

Applications

• Server

• PCs and Notebooks

• Network Switches

• Wearable Health and Fitness Devices

• Telecom Infrastructures

• Electronic Points of Sale
