SN74LV02APWT

四路2输入正或非门 QUADRUPLE 2-INPUT POSITIVE-NOR GATES

description

The ’LV02A devices are quadruple 2-input positive-NOR gates designed for 2-V to 5.5-V VCC operation.

2-V to 5.5-V VCC Operation

Max tpd of 6.5ns at 5V

Typical VOLPOutput Ground Bounce

   <0.8 V at VCC = 3.3 V, TA= 25°C

Typical VOHVOutput VOH Undershoot

   >2.3 V at VCC = 3.3 V, TA= 25°C

Support Mixed-Mode Voltage Operation on All Ports

Ioff Supports Partial-Power-Down Mode Operation

得捷:
IC GATE NOR 4CH 2-INP 14TSSOP

立创商城:
SN74LV02APWT

德州仪器TI:
4-ch, 2-input, 2-V to 5.5-V NOR gates

贸泽:
逻辑门 Quadruple 2-Inputs Positive-NOR Gate

艾睿:
NOR Gate 4-Element 2-IN CMOS 14-Pin TSSOP T/R

安富利:
NOR Gate 4-Element 2-IN CMOS 14-Pin TSSOP T/R

Verical:
NOR Gate 4-Element 2-IN CMOS 14-Pin TSSOP T/R
