TEXAS INSTRUMENTS SN74LVC2G38DCUT 与非门, LVC系列, 2输入, 32 mA, 1.65V至5.5V, VSSOP-8
与非门 IC 2 通道 开路漏极 8-VSSOP
立创商城:
SN74LVC2G38DCUT
德州仪器TI:
2-ch, 2-input, 1.65-V to 5.5-V NAND gates with open-drain outputs
得捷:
IC GATE NAND OD 2CH 2-INP 8VSSOP
贸泽:
Logic Gates Dual 2 Input NAND Gate
e络盟:
TEXAS INSTRUMENTS SN74LVC2G38DCUT 与非门, LVC系列, 2输入, 32 mA, 1.65V至5.5V, VSSOP-8
艾睿:
Thanks to Texas Instruments and their SN74LVC2G38DCUT logic gates, you can simplify your circuit down to a fundamental level. With an open drain output, this is power management at its best. This gate has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This device has a typical operating supply voltage of 1.8|2.5|3.3|5 V. Its minimum operating supply voltage of 1.65 V, while its maximum is 5.5 V.
Chip1Stop:
NAND Gate 2-Element 2-IN CMOS 8-Pin VSSOP T/R
Verical:
NAND Gate 2-Element 2-IN CMOS 8-Pin VSSOP T/R
电源电压DC 1.65V ~ 5.50V
输出接口数 1
输出电流 32 mA
电路数 2
针脚数 8
位数 2
传送延迟时间 3.90 ns
电压波节 5.00 V, 3.30 V, 2.50 V, 1.80 V
逻辑门个数 2
输入数 2
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 1.65V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 1.65 V
安装方式 Surface Mount
引脚数 8
封装 VSSOP-8
长度 2.3 mm
宽度 2 mm
高度 0.85 mm
封装 VSSOP-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LVC2G38DCUT TI 德州仪器 | 当前型号 | 当前型号 |
SN74LVC2G38DCUR 德州仪器 | 类似代替 | SN74LVC2G38DCUT和SN74LVC2G38DCUR的区别 |
SN74LVC2G38DCUTG4 德州仪器 | 类似代替 | SN74LVC2G38DCUT和SN74LVC2G38DCUTG4的区别 |
SN74LVC2G38DCURE4 德州仪器 | 类似代替 | SN74LVC2G38DCUT和SN74LVC2G38DCURE4的区别 |
