八路缓冲器/驱动器,具有三态输出 OCTAL BUFFERS/DRIVERS WITH 3-STATE OUTPUTS
The SNx4AHCT240 octal buffers/drivers are designed specifically to improve both the performance and density of 3-state memory-address drivers, clock drivers, and bus-oriented receivers and transmitters.
立创商城:
SN74AHCT240PWR
得捷:
IC BUFFER INVERT 5.5V 20TSSOP
德州仪器TI:
8-ch, 4.5-V to 5.5-V inverters with TTL-compatible CMOS inputs
艾睿:
Amplify analog and digital signals by driving the input to the transmission line with this SN74AHCT240PWR buffer and line driver from Texas Instruments. With a 3-state output, this is power management at its best. This line driver has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. It has 8 channels per chip. This inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.5 V, while its maximum is 5.5 V.
安富利:
Buffer/Line Driver 8-CH Inverting 3-ST CMOS 20-Pin TSSOP T/R
Verical:
Buffer/Line Driver 8-CH Inverting 3-ST CMOS 20-Pin TSSOP T/R
力源芯城:
八反相三态缓冲器/线驱动器
DeviceMart:
IC INVERTER DUAL 4-INPUT 20TSSOP
Win Source:
IC INVERTER DUAL 4-INPUT 20TSSOP
电源电压DC 4.50V ~ 5.50V
输出接口数 8
通道数 8
位数 8
传送延迟时间 10.0 ns
电压波节 5.00 V
输出电流驱动 -1.00 mA
输入数 8
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 4.5V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 4.5 V
安装方式 Surface Mount
引脚数 20
封装 TSSOP-20
封装 TSSOP-20
工作温度 -40℃ ~ 125℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74AHCT240PWR TI 德州仪器 | 当前型号 | 当前型号 |
SN74AHCT240PWRG4 德州仪器 | 完全替代 | SN74AHCT240PWR和SN74AHCT240PWRG4的区别 |
SN74AHCT240PWE4 德州仪器 | 完全替代 | SN74AHCT240PWR和SN74AHCT240PWE4的区别 |
SN74AHCT240PWG4 德州仪器 | 完全替代 | SN74AHCT240PWR和SN74AHCT240PWG4的区别 |
