SN74AHC541NSR

八路缓冲器/驱动器，具有三态输出 OCTAL BUFFERS/DRIVERS WITH 3-STATE OUTPUTS

description/ordering information

The ’AHC541 octal buffers/drivers are ideal for driving bus lines or buffer memory address registers. These devices feature inputs and outputs on opposite sides of the package to facilitate printed circuit board layout.

Operating Range 2-V to 5.5-V VCC

Latch-Up Performance Exceeds 250 mA Per JESD 17

得捷:
IC BUFFER NON-INVERT 5.5V 20SO

立创商城:
SN74AHC541NSR

德州仪器TI:
8-ch, 2-V to 5.5-V buffers with 3-state outputs

艾睿:
Leading the input to the transmission line this SN74AHC541NSR buffer and line driver by Texas Instruments will amplify digital and analog signals. With a 3-state output, this is power management at its best. This line driver has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. It has 8 channels per chip. This non-inverting device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 5.5 V.

安富利:
Buffer/Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin SOP T/R

Chip1Stop:
Buffer/Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin SOP T/R

Verical:
Buffer/Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin SOP T/R

Win Source:
IC BUFF/DVR TRI-ST 8BIT 20SO
