具有三态输出翻两番总线缓冲器GATES QUADRUPLE BUS BUFFER GATES WITH 3-STATE OUTPUTS
The AHC126 devices are quadruple bus buffer gates featuring independent line drivers with 3-state outputs. Each output is disabled when the associated output-enable OE input is low. When OE is high, the respective gate passes the data from the A input to its Y output.
To ensure the high-impedance state during power up or power down, OE should be tied to GND through a pulldown resistor; the minimum value of the resistor is determined by the current-sourcing capability of the driver.
得捷:
IC BUF NON-INVERT 5.5V 14SOIC
德州仪器TI:
4-ch, 2-V to 5.5-V buffers with 3-state outputs
艾睿:
Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin SOIC T/R
安富利:
Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin SOIC T/R
Chip1Stop:
Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin SOIC T/R
Verical:
Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin SOIC T/R
Newark:
# TEXAS INSTRUMENTS SN74AHC126DR Buffer, 74AHC126, 2 V to 5.5 V, SOIC-14
Win Source:
IC BUS BUFFER TRI-ST QD 14SOIC
电源电压DC 2.00V ~ 5.50V
输出接口数 4
电路数 4
通道数 4
位数 4
传送延迟时间 8.50 ns
电压波节 5.00 V, 3.30 V
输出电流驱动 -1.00 mA
输入数 4
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2V ~ 5.5V
电源电压Max 2 V
电源电压Min 5.5 V
安装方式 Surface Mount
引脚数 14
封装 SOIC-14
封装 SOIC-14
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74AHC126DR TI 德州仪器 | 当前型号 | 当前型号 |
SN74AHC126DE4 德州仪器 | 完全替代 | SN74AHC126DR和SN74AHC126DE4的区别 |
SN74AHC126DRG4 德州仪器 | 完全替代 | SN74AHC126DR和SN74AHC126DRG4的区别 |
SN74AHC126D 德州仪器 | 类似代替 | SN74AHC126DR和SN74AHC126D的区别 |
