SN74AHCT125NSR

具有三态输出翻两番总线缓冲器GATES QUADRUPLE BUS BUFFER GATES WITH 3-STATE OUTPUTS

The ’AHCT125 devices are quadruple bus buffer gates featuring independent line drivers with 3-state outputs. Each output is disabled when the associated output-enable OE\ input is high. When OE\ is low, the respective gate passes the data from the A input to its Y output.

To ensure the high-impedance state during power up or power down, OE\ should be tied to VCC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.

得捷:
IC BUFFER NON-INVERT 5.5V 14SOP

立创商城:
SN74AHCT125NSR

德州仪器TI:
4-ch, 4.5-V to 5.5-V buffers with TTL-compatible CMOS inputs and 3-state outputs

贸泽:
缓冲器和线路驱动器 Quad Bus Buff Gate With 3-State Outputs

艾睿:
Leading the input to the transmission line this SN74AHCT125NSR buffer and line driver by Texas Instruments will amplify digital and analog signals. With a 3-state output, this is power management at its best. This line driver has an operating temperature range of -40 °C to 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It has 4 channels per chip. This non-inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.5 V, while its maximum is 5.5 V.

Chip1Stop:
Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin SOP T/R

Verical:
Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin SOP T/R

DeviceMart:
IC BUS BUFFER TRI-ST QD 14SOP

Win Source:
IC BUS BUFFER TRI-ST QD 14SO
