74LV 系列,Texas Instruments低电压 CMOS 逻辑 工作电压:2 - 5.5 兼容性:输入 LVTTL/TTL、输出 LVCMOS ### 74LV 系列
74LV 系列,Texas Instruments
低电压 CMOS 逻辑
工作电压:2 - 5.5
兼容性:输入 LVTTL/TTL、输出 LVCMOS
### 74LV 系列
得捷:
IC BUF NON-INVERT 5.5V 14SSOP
欧时:
Texas Instruments SN74LV125ADBR LV 系列 4位 三态 非反相 缓冲器,线路驱动器, 14引脚 SSOP封装
立创商城:
SN74LV125ADBR
德州仪器TI:
4-ch, 2-V to 5.5-V buffers with 3-state outputs
艾睿:
Amplify analog and digital signals by driving the input to the transmission line with this SN74LV125ADBR buffer and line driver from Texas Instruments. With a 3-state output, this is power management at its best. This line driver has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This non-inverting device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 5.5 V. It has 4 channels per chip.
安富利:
Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin SSOP T/R
Chip1Stop:
Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin SSOP T/R
Verical:
Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin SSOP T/R
电源电压DC 2.00V ~ 5.50V
输出接口数 4
电路数 4
通道数 4
位数 4
传送延迟时间 9.50 ns
电压波节 5.00 V, 3.30 V, 2.50 V
输出电流驱动 -1.00 mA
输入数 4
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 14
封装 SSOP-14
长度 6.2 mm
宽度 5.3 mm
高度 1.95 mm
封装 SSOP-14
工作温度 -40℃ ~ 125℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LV125ADBR TI 德州仪器 | 当前型号 | 当前型号 |
SN74LV125ADBRG4 德州仪器 | 完全替代 | SN74LV125ADBR和SN74LV125ADBRG4的区别 |
SN74LV125ADB 德州仪器 | 完全替代 | SN74LV125ADBR和SN74LV125ADB的区别 |
SN74LV125ADBLE 德州仪器 | 完全替代 | SN74LV125ADBR和SN74LV125ADBLE的区别 |
