SN74AHC 系列,Texas Instruments过程:CMOS 电源电压:2 至 5.5 V ### 74AHC 系列
SN74AHC 系列,Texas Instruments
过程:CMOS
电源电压:2 至 5.5 V
得捷:
IC BUFFER INVERT 5.5V 20TSSOP
立创商城:
SN74AHC240PWR
德州仪器TI:
8-ch, 2-V to 5.5-V inverters with 3-state outputs
欧时:
Texas Instruments SN74AHC240PWR AHC 系列 8位 三态 反相 缓冲器,线路驱动器, 20引脚 TSSOP封装
艾睿:
By driving the input to the transmission line this SN74AHC240PWR buffer and line driver by Texas Instruments will amplify any signal. With a 3-state output, this is power management at its best. This line driver has an operating temperature range of -40 °C to 85 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This inverting device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 5.5 V. It has 8 channels per chip.
安富利:
Buffer/Line Driver 8-CH Inverting 3-ST CMOS 20-Pin TSSOP T/R
Chip1Stop:
Buffer/Line Driver 8-CH Inverting 3-ST CMOS 20-Pin TSSOP T/R
Verical:
Buffer/Line Driver 8-CH Inverting 3-ST CMOS 20-Pin TSSOP T/R
力源芯城:
八总线缓冲/驱动,三态
Win Source:
IC INVERTER DUAL 4-INPUT 20TSSOP
电源电压DC 2.00V ~ 5.50V
输出接口数 8
电路数 2
通道数 8
位数 8
传送延迟时间 8.50 ns
电压波节 5.00 V, 3.30 V
输出电流驱动 -1.00 mA
输入数 8
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2V ~ 5.5V
安装方式 Surface Mount
引脚数 20
封装 TSSOP-20
长度 6.5 mm
宽度 4.4 mm
高度 1.15 mm
封装 TSSOP-20
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74AHC240PWR TI 德州仪器 | 当前型号 | 当前型号 |
SN74AHC240PWRE4 德州仪器 | 完全替代 | SN74AHC240PWR和SN74AHC240PWRE4的区别 |
SN74AHC240PWRG4 德州仪器 | 完全替代 | SN74AHC240PWR和SN74AHC240PWRG4的区别 |
SN74AHC240PW 德州仪器 | 类似代替 | SN74AHC240PWR和SN74AHC240PW的区别 |
