具有三态输出翻两番总线缓冲器 QUADRUPLE BUS BUFFERS WITH 3-STATE OUTPUTS
缓冲器,非反向 4 元件 1 位每元件 三态 Output 14-SOIC
得捷:
IC BUF NON-INVERT 5.25V 14SOIC
立创商城:
SN74LS126ADR
德州仪器TI:
4-ch, 4.75-V to 5.25-V bipolar buffers with 3-state outputs
艾睿:
By driving the input to the transmission line this SN74LS126ADR buffer and line driver by Texas Instruments will amplify any signal. With a 3-state output, this is power management at its best. This line driver has an operating temperature range of 0 °C to 70 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. It has 4 channels per chip. This non-inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.75 V, while its maximum is 5.25 V.
安富利:
Buffer/Line Driver 4-CH Non-Inverting 3-ST Bipolar 14-Pin SOIC T/R
Chip1Stop:
Buffer/Line Driver 4-CH Non-Inverting 3-ST Bipolar 14-Pin SOIC T/R
Verical:
Buffer/Line Driver 4-CH Non-Inverting 3-ST Bipolar 14-Pin SOIC T/R
Newark:
# TEXAS INSTRUMENTS SN74LS126ADR Buffer, 74LS126, 4.75 V to 5.25 V, SOIC-14
DeviceMart:
IC BUS BUFF TRI-ST QD 14SOICN
电源电压DC 4.75V ~ 5.25V
输出接口数 4
通道数 4
位数 4
传送延迟时间 18.0 ns
电压波节 5.00 V
静态电流 12.0 mA
输出电流驱动 -108 µA
输入数 4
工作温度Max 70 ℃
工作温度Min 0 ℃
电源电压 4.75V ~ 5.25V
电源电压Max 4.75 V
电源电压Min 5.25 V
安装方式 Surface Mount
引脚数 14
封装 SOIC-14
封装 SOIC-14
工作温度 0℃ ~ 70℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LS126ADR TI 德州仪器 | 当前型号 | 当前型号 |
SN74LS126ADE4 德州仪器 | 完全替代 | SN74LS126ADR和SN74LS126ADE4的区别 |
SN74LS126AN 德州仪器 | 类似代替 | SN74LS126ADR和SN74LS126AN的区别 |
SN74LS126AD 德州仪器 | 类似代替 | SN74LS126ADR和SN74LS126AD的区别 |
