10位缓冲器/驱动器,具有三态输出 10-BIT BUFFER/DRIVER WITH 3-STATE OUTPUTS
缓冲器,非反向 1 元件 10 位每元件 三态 Output 24-TVSOP
立创商城:
SN74LVC827ADGVR
得捷:
IC BUF NON-INVERT 3.6V 24TVSOP
德州仪器TI:
10-ch, 1.65-V to 3.6-V buffers with 3-state outputs
艾睿:
Leading the input to the transmission line this SN74LVC827ADGVR buffer and line driver by Texas Instruments will amplify digital and analog signals. With a 3-state output, this is power management at its best. This line driver has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This non-inverting device has a typical operating supply voltage of 1.8|2.5|3.3 V. Its minimum operating supply voltage of 1.65 V, while its maximum is 3.6 V. It has 10 channels per chip.
安富利:
Buffer/Line Driver 10-CH Non-Inverting 3-ST CMOS 24-Pin TVSOP T/R
Chip1Stop:
Buffer/Line Driver 10-CH Non-Inverting 3-ST CMOS 24-Pin TVSOP T/R
Verical:
Buffer/Line Driver 10-CH Non-Inverting 3-ST CMOS 24-Pin TVSOP T/R
Win Source:
IC BUFF/DVR TRI-ST 10BIT 24TVSOP
电源电压DC 2.00V ~ 3.60V
输出接口数 10
通道数 10
位数 10
传送延迟时间 6.70 ns
电压波节 3.30 V, 2.70 V, 2.50 V, 1.80 V
输出电流驱动 -1.00 mA
输入数 10
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 1.65V ~ 3.6V
安装方式 Surface Mount
引脚数 24
封装 TVSOP-24
封装 TVSOP-24
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LVC827ADGVR TI 德州仪器 | 当前型号 | 当前型号 |
SN74LVC827APWT 德州仪器 | 完全替代 | SN74LVC827ADGVR和SN74LVC827APWT的区别 |
SN74LVC827ADBR 德州仪器 | 完全替代 | SN74LVC827ADGVR和SN74LVC827ADBR的区别 |
SN74LVC827ADBRG4 德州仪器 | 完全替代 | SN74LVC827ADGVR和SN74LVC827ADBRG4的区别 |
