16位缓冲器/驱动器,具有三态输出 16-BIT BUFFER/DRIVER WITH 3-STATE OUTPUTS
缓冲器,非反向 4 元件 4 位每元件 三态 Output 48-TVSOP
得捷:
IC BUF NON-INVERT 3.6V 48TVSOP
立创商城:
SN74ALVCH16244DGVR
德州仪器TI:
16-ch, 1.65-V to 3.6-V buffers with bus-hold and 3-state outputs
艾睿:
By driving the input to the transmission line this SN74ALVCH16244DGVR buffer and line driver by Texas Instruments will amplify any signal. With a 3-state output, this is power management at its best. This line driver has an operating temperature range of -40 °C to 85 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This non-inverting device has a typical operating supply voltage of 1.8|2.5|3.3 V. Its minimum operating supply voltage of 1.65 V, while its maximum is 3.6 V. It has 16 channels per chip.
安富利:
Buffer/Line Driver 16-CH Non-Inverting 3-ST CMOS 48-Pin TVSOP T/R
Chip1Stop:
Buffer/Line Driver 16-CH Non-Inverting 3-ST CMOS 48-Pin TVSOP T/R
Newark:
# TEXAS INSTRUMENTS SN74ALVCH16244DGVR Buffer / Line Driver, Non-Inverting, LVTTL, 1.65V to 3.6V, TVSOP-48
Win Source:
IC BUFF/DVR TRI-ST 16BIT 48TVSOP
电源电压DC 1.65V ~ 3.60V
输出接口数 16
通道数 16
位数 16
传送延迟时间 3.00 ns
电压波节 3.30 V, 2.70 V, 2.50 V, 1.80 V
输出电流驱动 -1.00 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 1.65V ~ 3.6V
电源电压Max 1.65 V
电源电压Min 3.6 V
安装方式 Surface Mount
引脚数 48
封装 TVSOP-48
长度 9.7 mm
宽度 4.4 mm
高度 1.05 mm
封装 TVSOP-48
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74ALVCH16244DGVR TI 德州仪器 | 当前型号 | 当前型号 |
74ALVCH16244DGVRE4 德州仪器 | 类似代替 | SN74ALVCH16244DGVR和74ALVCH16244DGVRE4的区别 |
74ALVCH16244DGVRG4 德州仪器 | 类似代替 | SN74ALVCH16244DGVR和74ALVCH16244DGVRG4的区别 |
74ALVCH244DGVRE4 德州仪器 | 功能相似 | SN74ALVCH16244DGVR和74ALVCH244DGVRE4的区别 |
