2.5 V / 3.3 V 16位缓冲器/带3态输出驱动程序 2.5-V/3.3-V 16-BIT BUFFERS/DRIVERS WITH 3-STATE OUTPUTS
Leading the input to the transmission line this buffer and line driver by Texas Instruments will amplify digital and analog signals. With a 3-state output, this is power management at its best. This line driver has an operating temperature range of -40 °C to 85 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This non-inverting device has a typical operating supply voltage of 2.5|3.3 V. Its minimum operating supply voltage of 2.3 V, while its maximum is 3.6 V. It has 16 channels per chip.
电源电压DC 2.30V ~ 3.60V
输出接口数 16
通道数 16
位数 16
传送延迟时间 3.50 ns
电压波节 3.30 V, 2.50 V
静态电流 3.2 mA
输出电流驱动 -333 µA
输入数 16
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2.3V ~ 2.7V
电源电压Max 2.3 V
电源电压Min 3.6 V
安装方式 Surface Mount
引脚数 48
封装 SSOP-48
长度 15.88 mm
宽度 7.49 mm
高度 2.59 mm
封装 SSOP-48
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74ALVTH16244DLR TI 德州仪器 | 当前型号 | 当前型号 |
SN74ALVTH16244VR 德州仪器 | 完全替代 | SN74ALVTH16244DLR和SN74ALVTH16244VR的区别 |
SN74ALVTH162244DL 德州仪器 | 类似代替 | SN74ALVTH16244DLR和SN74ALVTH162244DL的区别 |
SN74ALVTH162244LR 德州仪器 | 类似代替 | SN74ALVTH16244DLR和SN74ALVTH162244LR的区别 |
