3.3 -V ABT八路缓冲器/驱动器,具有三态输出 3.3-V ABT OCTAL BUFFER/DRIVER WITH 3-STATE OUTPUTS
缓冲器,非反向 2 元件 4 位每元件 三态 Output 20-SSOP
得捷:
IC BUF NON-INVERT 3.6V 20SSOP
立创商城:
SN74LVTH244AQDBREP
德州仪器TI:
Enhanced product 8-ch, 2.7-V to 3.6-V buffers with bus-hold, TTL-compatible CMOS inputs and 3-state
艾睿:
Amplify analog and digital signals by driving the input to the transmission line with this SN74LVTH244AQDBREP buffer and line driver from Texas Instruments. With a 3-state output, this is power management at its best. This line driver has an operating temperature range of -40 °C to 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This non-inverting device has a typical operating supply voltage of 3.3 V. Its minimum operating supply voltage of 2.7 V, while its maximum is 3.6 V. It has 8 channels per chip.
安富利:
Buffer/Line Driver 8-CH Non-Inverting 3-ST BiCMOS 20-Pin SSOP T/R
Chip1Stop:
Buffer/Line Driver 8-CH Non-Inverting 3-ST BiCMOS 20-Pin SSOP T/R
Verical:
Buffer/Line Driver 8-CH Non-Inverting 3-ST BiCMOS 20-Pin SSOP T/R
DeviceMart:
IC BUFF/DVR TRI-ST DUAL 20SSOP
Win Source:
IC BUF NON-INVERT 3.6V 20SSOP / Buffer, Non-Inverting 2 Element 4 Bit per Element 3-State Output 20-SSOP
电源电压DC 2.70V ~ 3.60V
输出接口数 8
通道数 8
位数 8
传送延迟时间 4.70 ns
电压波节 3.30 V, 2.70 V
静态电流 14.0 mA
逻辑门个数 8
输出电流驱动 -750 µA
输入数 8
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 2.7V ~ 3.6V
电源电压Max 3.6 V
电源电压Min 2.7 V
安装方式 Surface Mount
引脚数 20
封装 SSOP-20
封装 SSOP-20
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LVTH244AQDBREP TI 德州仪器 | 当前型号 | 当前型号 |
V62/03667-01XE 德州仪器 | 完全替代 | SN74LVTH244AQDBREP和V62/03667-01XE的区别 |
SN74LVTH244ADBR 德州仪器 | 类似代替 | SN74LVTH244AQDBREP和SN74LVTH244ADBR的区别 |
SN74LVTH244ADBRG4 德州仪器 | 类似代替 | SN74LVTH244AQDBREP和SN74LVTH244ADBRG4的区别 |
