18位缓冲器/驱动器,具有三态输出 18-BIT BUFFERS/DRIVERS WITH 3-STATE OUTPUTS
缓冲器,非反向 2 元件 9 位每元件 三态 Output 56-SSOP
得捷:
IC BUF NON-INVERT 5.5V 56SSOP
立创商城:
SN74ABT16825DLR
德州仪器TI:
18-ch, 4.5-V to 5.5-V buffers with TTL-compatible CMOS inputs and 3-state outputs
艾睿:
By driving the input to the transmission line this SN74ABT16825DLR buffer and line driver by Texas Instruments will amplify any signal. With a 3-state output, this is power management at its best. This line driver has an operating temperature range of -40 °C to 85 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. It has 18 channels per chip. This non-inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.5 V, while its maximum is 5.5 V.
安富利:
Buffer/Line Driver 18-CH Non-Inverting 3-ST BiCMOS 56-Pin SSOP T/R
Chip1Stop:
Buffer/Line Driver 18-CH Non-Inverting 3-ST BiCMOS 56-Pin SSOP T/R
Verical:
Buffer/Line Driver 18-CH Non-Inverting 3-ST BiCMOS 56-Pin SSOP T/R
Win Source:
IC BUFF/DVR TRI-ST 18BIT 56SSOP
电源电压DC 4.50V ~ 5.50V
输出接口数 18
通道数 18
位数 18
传送延迟时间 4.40 ns
电压波节 5.00 V
输出电流驱动 -500 µA
输入数 18
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 4.5V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 4.5 V
安装方式 Surface Mount
引脚数 56
封装 SSOP-56
封装 SSOP-56
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74ABT16825DLR TI 德州仪器 | 当前型号 | 当前型号 |
SN74ABT16825DL 德州仪器 | 完全替代 | SN74ABT16825DLR和SN74ABT16825DL的区别 |
SN74ABT162825DL 德州仪器 | 完全替代 | SN74ABT16825DLR和SN74ABT162825DL的区别 |
SN74ABT162825DLR 德州仪器 | 完全替代 | SN74ABT16825DLR和SN74ABT162825DLR的区别 |
