具有三态输出的 16 位缓冲器/驱动器 48-TSSOP -40 to 85
缓冲器,反向 元件 4 位每元件 三态 Output 48-TSSOP
得捷:
IC BUFFER INVERT 3.6V 48TSSOP
立创商城:
SN74LVCZ16240ADGGR
德州仪器TI:
16-ch, 2.7-V to 3.6-V inverters with 3-state outputs
艾睿:
By driving the input to the transmission line this SN74LVCZ16240ADGGR buffer and line driver by Texas Instruments will amplify any signal. With a 3-state output, this is power management at its best. This line driver has a minimum operating temperature of -40 °C and a maximum of 85 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. It has 16 channels per chip. This inverting device has a typical operating supply voltage of 3.3 V. Its minimum operating supply voltage of 2.7 V, while its maximum is 3.6 V.
安富利:
Buffer/Line Driver 16-CH Inverting 3-ST CMOS 48-Pin TSSOP T/R
Chip1Stop:
Buffer/Line Driver 16-CH Inverting 3-ST CMOS 48-Pin TSSOP T/R
Verical:
Buffer/Line Driver 16-CH Inverting 3-ST CMOS 48-Pin TSSOP T/R
电源电压DC 2.70V ~ 3.60V
输出接口数 16
电路数 4
通道数 16
位数 16
传送延迟时间 4.20 ns
电压波节 3.30 V, 2.70 V
输出电流驱动 -1.00 mA
输入数 4
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2.7V ~ 3.6V
电源电压Max 3.6 V
电源电压Min 2.7 V
安装方式 Surface Mount
引脚数 48
封装 TSSOP-48
封装 TSSOP-48
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LVCZ16240ADGGR TI 德州仪器 | 当前型号 | 当前型号 |
SN74LVCH16240ADGGR 德州仪器 | 类似代替 | SN74LVCZ16240ADGGR和SN74LVCH16240ADGGR的区别 |
74LVCH16240ADGGRG4 德州仪器 | 类似代替 | SN74LVCZ16240ADGGR和74LVCH16240ADGGRG4的区别 |
74LVCH16240ADGGRE4 德州仪器 | 类似代替 | SN74LVCZ16240ADGGR和74LVCH16240ADGGRE4的区别 |
