SRN6028-1R5Y

BOURNS  SRN6028-1R5Y  表面贴装功率电感器, SRN6028系列, 1.5 µH, ± 30%, 半屏蔽, 0.021 ohm, 4.2 A

SRN6028 系列半磁性屏蔽式功率器

Bourns SRN6028 系列提供各种尺寸，具有半屏蔽结构。

**特点和优势：**

电感范围：0.90 μH 至 100 μH

额定电流：最大 4.6 A

符合 RoHS 标准且无卤

应用：直流-直流转换器、笔记本电脑、数码摄像机、HDD、手机、电视和 LCD 显示器

立创商城:
1.5uH ±30% 4.2A 21mΩ

得捷:
FIXED IND 1.5UH 4.2A 21 MOHM SMD

欧时:
### SRN6028 系列半磁性屏蔽式功率电感器SRN6028 系列具有半屏蔽结构 电感范围：0.90 至 100 μH 额定电流：最大 4.6 A 应用：直流/直流转换器、笔记本电脑、数码摄像机、HDD、手机、电视和 LCD 显示屏 ### Bourns 非标准表面安装电感器（扼流圈）

贸泽:
固定电感器 1.5uH 30% SMD 6028

e络盟:
功率电感SMD, 1.5 µH, 4.2 A, 半屏蔽, 5.1 A, SRN6028系列, 6mm x 6mm x 2.8mm

艾睿:
Does your electronic circuit design require filtering, power supplies, and other similar functions? Then this power SRN6028-1R5Y surface mount inductor from Bourns is perfect for you! This SMD inductor has an operating temperature range of -40 °C to 125 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This product is 6.2 mm long, 2.8 mm tall and 6.2 mm deep. This device utilizes wirewound technology. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 70MTyp Hz. This SMD inductor has a maximum DC current of 4.2 A with a maximum resistance of 21m Ohm. It has an inductance of 1.5u H.

Allied Electronics:
SMD Semi-Shielded Power Inductor; 1.5uH 1.2A 30% 6028

Verical:
Inductor Power Semi-Shielded Wirewound 1.5uH 30% 100KHz 12Q-Factor Ferrite 4.2A 0.021Ohm DCR 2424 T/R

Newark:
# BOURNS  SRN6028-1R5Y  Surface Mount Power Inductor, SRN6028 Series, 1.5 µH, 4.2 A, 5.1 A, Semishielded, 0.021 ohm

Online Components:
Inductor Power Semi-Shielded Wirewound 1.5uH 30% 100KHz 12Q-Factor Ferrite 4.2A 21mOhm DCR 2424 T/R

Electro Sonic:
Inductor Power Semi-Shielded Wirewound 1.5uH 30% 100KHz 12Q-Factor Ferrite 4.2A 21mOhm DCR 2424 T/R
