SRN6028-330M

BOURNS  SRN6028-330M  表面贴装功率电感器, SRN6028系列, 33 µH, ± 20%, 半屏蔽, 0.264 ohm, 1.1 A

SRN6028 系列半磁性屏蔽式功率器

Bourns SRN6028 系列提供各种尺寸，具有半屏蔽结构。

**特点和优势：**

电感范围：0.90 μH 至 100 μH

额定电流：最大 4.6 A

符合 RoHS 标准且无卤

应用：直流-直流转换器、笔记本电脑、数码摄像机、HDD、手机、电视和 LCD 显示器

欧时:
### SRN6028 系列半磁性屏蔽式功率电感器Bourns SRN6028 Series comes in various sizes and have a semi-shielded construction.SRN6028 系列具有半屏蔽结构 电感范围：0.90 至 100 μH 额定电流：最大 4.6 A 应用：直流/直流转换器、笔记本电脑、数码摄像机、HDD、手机、电视和 LCD 显示屏 ### Bourns 非标准表面安装电感器（扼流圈）

得捷:
FIXED IND 33UH 1.1A 264 MOHM SMD

立创商城:
33uH ±20% 1.1A 264mΩ

e络盟:
功率电感SMD, 33 µH, 1.1 A, 半屏蔽, 1.1 A, SRN6028系列, 6mm x 6mm x 2.8mm

艾睿:
An ideal space-saving electronic component is this power SRN6028-330M surface mount inductor from Bourns. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This device is made with wirewound technology. It has a tolerance of 20%. This SMD inductor has a maximum DC current of 1.1 A with a maximum resistance of 264m Ohm. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 10MTyp Hz. This product is 6.2 mm long, 2.8 mm tall and 6.2 mm deep. It has an inductance of 33u H.

Allied Electronics:
SMD Semi-Shielded Power Inductor; 33uH 1.1A 20% 6028

安富利:
Ind Power Semi-Shielded Wirewound 33uH 20% 100KHz Ferrite 1.1A 6028 T/R

Verical:
Inductor Power Semi-Shielded Wirewound 33uH 20% 100KHz 11Q-Factor Ferrite 1.1A 0.264Ohm DCR 2424 T/R

Newark:
# BOURNS  SRN6028-330M  Surface Mount Power Inductor, SRN6028 Series, 33 µH, 1.1 A, 1.1 A, Semishielded, 0.264 ohm

Online Components:
Inductor Power Semi-Shielded Wirewound 33uH 20% 100KHz 11Q-Factor Ferrite 1.1A 264mOhm DCR 2424 T/R

Electro Sonic:
Inductor Power Semi-Shielded Wirewound 33uH 20% 100KHz 11Q-Factor Ferrite 1.1A 264mOhm DCR 2424 T/R
