SDE0805A-100M

BOURNS  SDE0805A-100M  表面贴装功率电感器, AEC-Q200 SDE0805A系列, 10 µH, ± 20%, 非屏蔽, 0.07 ohm, 3.2 A

器

立创商城:
10uH ±20% 3.2A 50mΩ

得捷:
FIXED IND 10UH 3.2A 70 MOHM SMD

e络盟:
功率电感SMD, 10 µH, 3.2 A, 非屏蔽, 2.6 A, SDE0805A 系列, 7.8mm x 7mm x 5mm

艾睿:
Is space on a PCB a limiting factor for your electronic circuit design? Then use this power SDE0805A-100M surface mount inductor from Bourns to save valuable space. This SMD inductor has an operating temperature range of -40 °C to 125 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. It has an inductance of 10u H. Its test frequency is 1M Hz, while its minimum self-resonant frequency is 27.5MTyp Hz. This SMD inductor has a maximum DC current of 3.2Typ A with a maximum resistance of 70m Ohm. This device utilizes wirewound technology. It has a tolerance of 20%. This product is 8.1 mm long, 5.5 mm tall and 7.3 mm deep.

Allied Electronics:
SMD Non-Shielded Power Inductor; 10uH; 20%; SDE0805A

安富利:
Ind Power 10uH 20% 1MHz Ferrite 3.2A T/R

Verical:
Inductor Power Unshielded Wirewound 10uH 20% 1MHz Ferrite 3.2A 0.07Ohm DCR Automotive T/R

Newark:
# BOURNS  SDE0805A-100M  Surface Mount Power Inductor, AEC-Q200 SDE0805A Series, 10 H, 20%, Unshielded, 0.07 ohm, 3.2 A

Online Components:
Inductor Power Unshielded Wirewound 10uH 20% 1MHz Ferrite 3.2A 70mOhm DCR Automotive T/R

Electro Sonic:
Inductor Power Unshielded Wirewound 10uH 20% 1MHz Ferrite 3.2A 70mOhm DCR Automotive T/R
