SDR0703-680KL

SMD功率电感 SMD Power Inductors

无屏蔽 绕线 器 900 毫欧最大 非标准

立创商城:
68uH ±10% 380mA 900mΩ

得捷:
FIXED IND 68UH 380MA 900MOHM SMD

贸泽:
Fixed Inductors 68uH 10% SMD 0703

艾睿:
Use this power SDR0703-680KL surface mount inductor from Bourns to make any circuit look clean and compact. This SMD inductor has an operating temperature range of -40 °C to 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 13M Hz. It has an inductance of 68u H. This SMD inductor has a maximum DC current of 380m A with a maximum resistance of 900m Ohm. It has a tolerance of 10%. This product is 6.8 mm long, 2.9 mm tall and 4.7 mm deep. This device utilizes wirewound technology.

Allied Electronics:
Inductor; Power Wirewound; 68uH; 380mA; 10%; SMD

安富利:
Ind Power Wirewound 68uH 10% 100KHz 18Q-Factor Ferrite 380mA T/R

Verical:
Inductor Power Unshielded Wirewound 68uH 10% 100KHz 18Q-Factor Ferrite 0.38A 0.9Ohm DCR T/R

Newark:
# BOURNS  SDR0703-680KL  Surface Mount Power Inductor, SDR0703 Series, 68 µH, 380 mA, 560 mA, Unshielded, 0.9 ohm

MASTER:
Inductor Power Wirewound 68uH 10% 100KHz 18Q-Factor Ferrite 380mA 900mOhm DCR T/R

Online Components:
Inductor Power Wirewound 68uH 10% 100KHz 18Q-Factor Ferrite 380mA 900mOhm DCR T/R

Electro Sonic:
Inductor Power Wirewound 68uH 10% 100KHz 18Q-Factor Ferrite 380mA 900mOhm DCR T/R

Win Source:
FIXED IND 68UH 380MA 900MOHM SMD / 68 µH Unshielded Drum Core, Wirewound Inductor 380 mA 900mOhm Max Nonstandard
