SRR5028-151Y

SRR5028系列 - 屏蔽贴片功率电感 SRR5028 Series - Shielded SMD Power Inductors

150µH Shielded Wirewound Inductor 330mA 900mOhm Max Nonstandard

立创商城:
150uH ±30% 330mA 900mΩ

得捷:
FIXED IND 150UH 330MA 900MOHM SM

艾睿:
This power SRR5028-151Y surface mount inductor from Bourns is ideal for applications where space is a major influence of circuit design. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 7.5MTyp Hz. This device is made with wirewound technology. It has an inductance of 150u H. This product is 6.1 mm long, 3 mm tall and 6.1 mm deep. This SMD inductor has a maximum DC current of 330m A with a maximum resistance of 900m Ohm.

安富利:
Ind Power Shielded Wirewound 150uH 30% 100KHz 7Q-Factor Ferrite 330mA T/R

Verical:
Inductor Power Shielded Wirewound 150uH 30% 100KHz 7Q-Factor Ferrite 0.33A 0.9Ohm DCR T/R
