SRR4028-1R8Y

SRR4028系列 - 屏蔽贴片功率电感 SRR4028 Series - Shielded SMD Power Inductors

屏蔽 绕线 器 25 毫欧最大 1919（4848 公制）

得捷:
FIXED IND 1.8UH 2.7A 25 MOHM SMD

立创商城:
1.8uH ±30% 2.7A 25mΩ

艾睿:
Does your electronic circuit design require filtering, power supplies, and other similar functions? Then this power SRR4028-1R8Y surface mount inductor from Bourns is perfect for you! This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 146MTyp Hz. This device is made with wirewound technology. It has an inductance of 1.8u H. This SMD inductor has a maximum DC current of 2.7 A with a maximum resistance of 25m Ohm. This product is 5 mm long, 3 mm tall and 5 mm deep.

安富利:
Ind Power Shielded Wirewound 1.8uH 30% 100KHz 9.18Q-Factor Ferrite 2.7A T/R

Chip1Stop:
Ind Power Shielded Wirewound 1.8uH 30% 100KHz 9.18Q-Factor Ferrite 2.7A T/R

Verical:
Inductor Power Shielded Wirewound 1.8uH 30% 100KHz 9.18Q-Factor Ferrite 2.7A 0.025Ohm DCR T/R

Online Components:
Inductor Power Shielded Wirewound 1.8uH 30% 100KHz 9.18Q-Factor Ferrite 2.7A 25mOhm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 1.8uH 30% 100KHz 9.18Q-Factor Ferrite 2.7A 25mOhm DCR T/R
