SRR7032-2R2M

BOURNS  SRR7032-2R2M  表面贴装功率电感器, SRR7032系列, 2.2 µH, ± 20%, 屏蔽, 0.022 ohm, 2.65 A

屏蔽 绕线 器 22 毫欧最大 非标准

得捷:
FIXED IND 2.2UH 2.65A 22MOHM SMD

立创商城:
2.2uH ±20% 2.65A 22mΩ

e络盟:
功率电感SMD, 2.2 µH, 2.65 A, 屏蔽, 2.6 A, SRR7032系列, 7mm x 7mm x 3.2mm

艾睿:
An ideal space-saving electronic component is this power SRR7032-2R2M surface mount inductor from Bourns. This SMD inductor has an operating temperature range of -40 °C to 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This device utilizes wirewound technology. This SMD inductor has a maximum DC current of 2.65 A with a maximum resistance of 22m Ohm. This product is 7.3 mm long, 3.4 mm tall and 7.3 mm deep. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 70MTyp Hz. It has a tolerance of 20%. It has an inductance of 2.2u H.

安富利:
Ind Power Shielded Wirewound 2.2uH 20% 100KHz 12Q-Factor Ferrite 2.65A T/R

Verical:
Inductor Power Shielded Wirewound 2.2uH 20% 1KHz 12Q-Factor Ferrite 2.65A 0.022Ohm DCR T/R

Newark:
# BOURNS  SRR7032-2R2M  Surface Mount Power Inductor, SRR7032 Series, 2.2 H, 20%, Shielded, 0.022 ohm, 2.65 A
