SRR4018-270Y

SHIELDED SMD功率电感 Shielded SMD Power Inductors

屏蔽 绕线 器 370 毫欧最大 1919（4848 公制）

得捷:
FIXED IND 27UH 770MA 370MOHM SMD

贸泽:
Fixed Inductors 27uH 30% SMD 4018

艾睿:
This power SRR4018-270Y surface mount inductor from Bourns is placed on the surface of a PCB during surface mount manufacturing processing. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 23MTyp Hz. It has an inductance of 27u H. This product is 5 mm long, 2 mm tall and 5 mm deep. This device is made with wirewound technology. This SMD inductor has a maximum DC current of 770m A with a maximum resistance of 370m Ohm.

安富利:
Ind Power Shielded Wirewound 27uH 30% 100KHz 7Q-Factor Ferrite 770mA T/R

Verical:
Inductor Power Shielded Wirewound 27uH 30% 100KHz 7Q-Factor Ferrite 0.77A 0.37Ohm DCR T/R

Online Components:
Inductor Power Shielded Wirewound 27uH 30% 100KHz 7Q-Factor Ferrite 770mA 370mOhm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 27uH 30% 100KHz 7Q-Factor Ferrite 770mA 370mOhm DCR T/R
