SDR1006-152KL

BOURNS  SDR1006-152KL  表面贴装功率电感器, SDR1006系列, 1.5 mH, ± 10%, 非屏蔽, 5 ohm, 190 mA

SDR1006 系列线绕扼流圈

提供 E12 系列

小型设计，最大直径仅 9.8mm

符合 RoHs

应用于直流/直流转换器的输入/输出以及电源

立创商城:
1.5mH ±10% 190mA 5Ω

得捷:
FIXED IND 1.5MH 190MA 5 OHM SMD

欧时:
### SDR1006 系列线绕扼流圈提供 E12 系列 小型设计，最大直径仅 9.8mm 符合 RoHs 应用于直流/直流转换器的输入/输出以及电源 ### Bourns 非标准表面安装电感器（扼流圈）

e络盟:
功率电感SMD, 1.5 mH, 190 mA, 非屏蔽, 450 mA, SDR1006系列, 9.8mm x 9.8mm x 5.8mm

艾睿:
Does your electronic circuit design require filtering, power supplies, and other similar functions? Then this power SDR1006-152KL surface mount inductor from Bourns is perfect for you! This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. It has an inductance of 1.5m H. This SMD inductor has a maximum DC current of 190m A with a maximum resistance of 5 Ohm. This product is 5.8 mm tall with a diameter of 9.8 mm. It has a tolerance of 10%. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 1.7M Hz. This device is made with wirewound technology.

Allied Electronics:
SDR1006 WireWound SMDinductor w/FerriteCore, 1.5 mH +/-10% 450mA Idc Q:31

安富利:
Ind Power Wirewound 1.5mH 10% 1KHz 31Q-Factor Ferrite 190mA T/R

Chip1Stop:
Inductor Power Wirewound 1.5mH 10% 1KHz 31Q-Factor Ferrite 190mA 5Ohm DCR T/R

Verical:
Inductor Power Unshielded Wirewound 1500uH 10% 1KHz 31Q-Factor Ferrite 0.19A 5Ohm DCR T/R

Newark:
# BOURNS  SDR1006-152KL  Surface Mount Power Inductor, SDR1006 Series, 1.5 mH, 190 mA, 450 mA, Unshielded, 5 ohm

Online Components:
Inductor Power Wirewound 1.5mH 10% 1KHz 31Q-Factor Ferrite 190mA 5Ohm DCR T/R

Electro Sonic:
Inductor Power Wirewound 1.5mH 10% 1KHz 31Q-Factor Ferrite 190mA 5Ohm DCR T/R
