SDR1006-120ML

BOURNS  SDR1006-120ML  表面贴装功率电感器, SDR1006系列, 12 µH, ± 20%, 非屏蔽, 0.07 ohm, 2.45 A

12 µH 无屏蔽 器 2.45 A 70 毫欧最大 非标准

得捷:
FIXED IND 12UH 2.45A 70 MOHM SMD

欧时:
### SDR1006 系列线绕扼流圈提供 E12 系列 小型设计，最大直径仅 9.8mm 符合 RoHs 应用于直流/直流转换器的输入/输出以及电源 ### Bourns 非标准表面安装电感器（扼流圈）

e络盟:
功率电感SMD, 12 µH, 2.45 A, 非屏蔽, 4.5 A, SDR1006系列, 9.8mm x 9.8mm x 5.8mm

艾睿:
This power SDR1006-120ML surface mount inductor from Bourns is ideal for saving valuable space on a PCB. This SMD inductor has an operating temperature range of -40 °C to 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This product is 5.8 mm tall with a diameter of 9.8 mm. It has an inductance of 12u H. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 20M Hz. This device utilizes wirewound technology. It has a tolerance of 20%. This SMD inductor has a maximum DC current of 2.45 A with a maximum resistance of 70m Ohm.

Allied Electronics:
Power inductor SMD 12uH 2.25A

安富利:
Ind Power Wirewound 12uH 20% 1KHz 30Q-Factor Ferrite 2.45A T/R

Chip1Stop:
Inductor Power Wirewound 12uH 20% 1KHz 30Q-Factor Ferrite 2.45A 70mOhm DCR T/R

Verical:
Inductor Power Unshielded Wirewound 12uH 20% 1KHz 30Q-Factor Ferrite 2.45A 0.07Ohm DCR T/R

Electro Sonic:
Inductor Power Wirewound 12uH 20% 1KHz 30Q-Factor Ferrite 2.45A 0.07Ohm DCR T/R
