SRU6025-470Y

SRU6025系列 - 屏蔽贴片功率电感 SRU6025 Series - Shielded SMD Power Inductors

Inductor Power Shielded Wirewound 47uH 30% 100KHz 12Q-Factor Ferrite 1A 250mOhm DCR T/R

得捷:
FIXED IND 47UH 1A 250 MOHM SMD

艾睿:
Make any circuit look clean and compact using this power SRU6025-470Y surface mount inductor from Bourns. This SMD inductor has an operating temperature range of -40 °C to 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This product is 6.8 mm long, 2.8 mm tall and 6.8 mm deep. It has an inductance of 47u H. This device utilizes wirewound technology. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 10M Hz. This SMD inductor has a maximum DC current of 1 A with a maximum resistance of 250m Ohm.

安富利:
Ind Power Shielded Wirewound 47uH 30% 100KHz 12Q-Factor Ferrite 1A T/R

Verical:
Inductor Power Shielded Wirewound 47uH 30% 100KHz 12Q-Factor Ferrite 1A 0.25Ohm DCR T/R

Online Components:
Inductor Power Shielded Wirewound 47uH 30% 100KHz 12Q-Factor Ferrite 1A 250mOhm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 47uH 30% 100KHz 12Q-Factor Ferrite 1A 0.25Ohm DCR T/R
