SRU8028-220Y

BOURNS  SRU8028-220Y  功率电感, 22uH, 30%容差, 8028封装

22 µH 屏蔽 绕线 器 1.6 A 106 毫欧 非标准

立创商城:
22uH ±30% 1.6A 106mΩ

得捷:
FIXED IND 22UH 1.6A 106 MOHM SMD

e络盟:
BOURNS  SRU8028-220Y  功率电感, 22uH, 30%容差, 8028封装

艾睿:
Save valuable space on a PCB with this power SRU8028-220Y surface mount inductor from Bourns. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. It has an inductance of 22u H. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 20MTyp Hz. This SMD inductor has a maximum DC current of 1.6 A with a maximum resistance of 106m Ohm. This product is 8.3 mm long, 3.1 mm tall and 8.3 mm deep. This device is made with wirewound technology.

安富利:
Ind Power Shielded Wirewound 22uH 30% 100KHz 22Q-Factor Ferrite 1.6A T/R

Chip1Stop:
Ind Power Shielded Wirewound 22uH 30% 100KHz 22Q-Factor Ferrite 1.6A T/R

Verical:
Inductor Power Shielded Wirewound 22uH 30% 100KHz 22Q-Factor Ferrite 1.6A 0.106Ohm DCR 3131 T/R

Newark:
# BOURNS  SRU8028-220Y  Surface Mount Power Inductor, SRU8028 Series, 22 µH, 1.6 A, 1.5 A, Shielded, 0.106 ohm

MASTER:
Inductor Power Shielded Wirewound 22uH 30% 100KHz 22Q-Factor Ferrite 1.6A 106mOhm DCR 3131 T/R

Online Components:
Inductor Power Shielded Wirewound 22uH 30% 100KHz 22Q-Factor Ferrite 1.6A 106mOhm DCR 3131 T/R

Electro Sonic:
Inductor Power Shielded Wirewound 22uH 30% 100KHz 22Q-Factor Ferrite 1.6A 106mOhm DCR 3131 T/R

Win Source:
FIXED IND 22UH 1.6A 106 MOHM SMD / 22 µH Shielded Drum Core, Wirewound Inductor 1.6 A 106mOhm Nonstandard
