SRU1048-3R0Y

SRU1048 系列磁性屏蔽线绕扼流圈薄型屏蔽结构 高电流额定值。 非常适合于高频率。 应用：直流/直流转换器，EMI 滤波器。 ### Bourns 非标准表面安装电感器（扼流圈）

SRU1048 系列磁性屏蔽线绕扼流圈

薄型屏蔽结构

高电流额定值。

非常适合于高频率。

应用：直流/直流转换器，EMI 滤波器。

得捷:
FIXED IND 3UH 6.2A 7.2 MOHM SMD

欧时:
### SRU1048 系列磁性屏蔽线绕扼流圈薄型屏蔽结构 高电流额定值。 非常适合于高频率。 应用：直流/直流转换器，EMI 滤波器。 ### Bourns 非标准表面安装电感器（扼流圈）

立创商城:
3uH ±30% 6.2A 7.2mΩ

艾睿:
An ideal space-saving electronic component is this power SRU1048-3R0Y surface mount inductor from Bourns. This SMD inductor has an operating temperature range of -40 °C to 125 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This product is 10.3 mm long, 5.1 mm tall and 10.3 mm deep. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 40MTyp Hz. It has an inductance of 3u H. This SMD inductor has a maximum DC current of 6.2 A with a maximum resistance of 7.2m Ohm. This device utilizes wirewound technology.

Allied Electronics:
SRU1048 Series Wire-wound SMD Inductor w/ Ferrite Core; 3 uH +/-30% 6.2A Idc Q:14

安富利:
Ind Power Shielded Wirewound 3uH 30% 100KHz 14Q-Factor Ferrite 6.2A T/R

Verical:
Inductor Power Shielded Wirewound 3uH 30% 100KHz 14Q-Factor Ferrite 6.2A 0.0072Ohm DCR T/R

MASTER:
Inductor Power Shielded Wirewound 3uH 30% 100KHz 14Q-Factor Ferrite 6.2A 7.2mOhm DCR T/R

Online Components:
Inductor Power Shielded Wirewound 3uH 30% 100KHz 14Q-Factor Ferrite 6.2A 7.2mOhm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 3uH 30% 100KHz 14Q-Factor Ferrite 6.2A 7.2mOhm DCR T/R
