SHIELDED SMD功率电感 Shielded SMD Power Inductors
Inductor Power Shielded Wirewound 15uH 30% 100KHz 20Q-Factor Ferrite 2A 66mOhm DCR 3131 T/R
得捷:
FIXED IND 15UH 2A 66 MOHM SMD
立创商城:
15uH ±30% 2A 66mΩ
艾睿:
Use this power SRU8028-150Y surface mount inductor from Bourns to make any circuit look clean and compact. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This device is made with wirewound technology. This SMD inductor has a maximum DC current of 2 A with a maximum resistance of 66m Ohm. This product is 8.3 mm long, 3.1 mm tall and 8.3 mm deep. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 25MTyp Hz. It has an inductance of 15u H.
安富利:
Ind Power Shielded Wirewound 15uH 30% 100KHz 20Q-Factor Ferrite 2A T/R
Verical:
Inductor Power Shielded Wirewound 15uH 30% 100KHz 20Q-Factor Ferrite 2A 0.066Ohm DCR 3131 T/R
MASTER:
Inductor Power Shielded Wirewound 15uH 30% 100KHz 20Q-Factor Ferrite 2A 66mOhm DCR 3131 T/R
Online Components:
Inductor Power Shielded Wirewound 15uH 30% 100KHz 20Q-Factor Ferrite 2A 66mOhm DCR 3131 T/R
Electro Sonic:
Inductor Power Shielded Wirewound 15uH 30% 100KHz 20Q-Factor Ferrite 2A 66mOhm DCR 3131 T/R
