SRU1048-6R8Y

BOURNS  SRU1048-6R8Y  表面贴装功率电感器, SRU1048系列, 6.8 µH, ± 30%, 屏蔽, 0.0136 ohm, 4.8 A

SRU1048 系列磁性屏蔽线绕扼流圈

薄型屏蔽结构

高电流额定值。

非常适合于高频率。

应用：直流/直流转换器，EMI 滤波器。

得捷:
FIXED IND 6.8UH 4.8A 13.6MOHM SM

欧时:
Bourns SRU1048 系列 屏蔽 铁氧体芯材 6.8 μH 绕线贴片电感器 SRU1048-6R8Y, ±30%容差, 4.8A Idc Q:10

立创商城:
6.8uH ±30% 4.8A 13.6mΩ

e络盟:
功率电感SMD, 6.8 µH, 4.8 A, 屏蔽, 4.1 A, SRU1048系列, 10mm x 10mm x 4.8mm

艾睿:
This power SRU1048-6R8Y surface mount inductor from Bourns is placed on the surface of a PCB during surface mount manufacturing processing. This SMD inductor has an operating temperature range of -40 °C to 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This device utilizes wirewound technology. It has an inductance of 6.8u H. This product is 10.3 mm long, 5.1 mm tall and 10.3 mm deep. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 20MTyp Hz. This SMD inductor has a maximum DC current of 4.8 A with a maximum resistance of 13.6m Ohm.

Allied Electronics:
Inductor; Power; Shielded; Wirewound; 6.8uH; 30%; 4.8A

安富利:
Ind Power Shielded Wirewound 6.8uH 30% 100KHz 10Q-Factor Ferrite 4.8A T/R

Verical:
Inductor Power Shielded Wirewound 6.8uH 30% 100KHz 10Q-Factor Ferrite 4.8A 0.0136Ohm DCR T/R

Newark:
# BOURNS  SRU1048-6R8Y  Surface Mount Power Inductor, SRU1048 Series, 6.8 µH, 4.8 A, 4.1 A, Shielded, 0.0136 ohm

MASTER:
Inductor Power Shielded Wirewound 6.8uH 30% 100KHz 10Q-Factor Ferrite 4.8A 13.6mOhm DCR T/R

Online Components:
Inductor Power Shielded Wirewound 6.8uH 30% 100KHz 10Q-Factor Ferrite 4.8A 13.6mOhm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 6.8uH 30% 100KHz 10Q-Factor Ferrite 4.8A 13.6mOhm DCR T/R
