BOURNS SRP6540-1R0M 表面贴装功率电感器, SRP6540系列, 1 µH, ± 20%, 屏蔽, 7200 µohm, 12 A
SRP6540 系列磁性屏蔽线绕扼流圈
屏蔽结构
铁粉核芯
高饱和电流
应用包括用于便携式设备的直流/直流转换器和电源
立创商城:
1uH ±20%
欧时:
Bourns SRP6540 系列 屏蔽 铁芯材 1 μH 绕线贴片电感器 SRP6540-1R0M, ±20%容差, 12A Idc
得捷:
FIXED IND 1UH 12A 7.2 MOHM SMD
贸泽:
Fixed Inductors 1uH 20% SMD 6540
e络盟:
功率电感SMD, 1 µH, 12 A, 屏蔽, 13.5 A, SRP6540系列, 7.2mm x 6.5mm x 4mm
艾睿:
Save valuable space on a PCB with this power SRP6540-1R0M surface mount inductor from Bourns. This SMD inductor has an operating temperature range of -55 °C to 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. It has an inductance of 1u H. This SMD inductor has a maximum DC current of 12Typ A with a maximum resistance of 7.2m Ohm. Its test frequency is 100K Hz. It has a tolerance of 20%. This product is 7.5 mm long, 4 mm tall and 6.7 mm deep. This device utilizes wirewound technology.
Allied Electronics:
SRP6540 Series Shielded Wire-wound SMD Inductor w/ Iron Core, 1 uH +/-20% 12A Idc
安富利:
Ind Power Shielded Wirewound 1uH 20% 100KHz Powdered Iron 12A T/R
Chip1Stop:
Ind Power Shielded/Molded Wirewound 1uH 20% 100KHz Powdered Iron 12A T/R
Verical:
Inductor Power Shielded/Molded Wirewound 1uH 20% 100KHz Powdered Iron 12A 0.0072Ohm DCR T/R
Newark:
# BOURNS SRP6540-1R0M Surface Mount Power Inductor, SRP6540 Series, 1 µH, 12 A, 13.5 A, Shielded, 7200 µohm
额定电流 12 A
容差 ±20 %
电感 1 µH
自谐频率 100 kHz
电感公差 ±20 %
测试频率 100 kHz
电阻DC) ≤7.2 mΩ
工作温度Max 125 ℃
工作温度Min -55 ℃
电阻DC Max 0.0072 Ω
安装方式 Surface Mount
引脚数 2
封装 7.2mm x 6.5mm x 4mm
长度 7.2 mm
宽度 6.7 mm
高度 4 mm
封装 7.2mm x 6.5mm x 4mm
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Cut Tape CT
RoHS标准 RoHS Compliant
含铅标准 无铅
REACH SVHC标准 No SVHC
REACH SVHC版本 2016/06/20
香港进出口证 NLR
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SRP6540-1R0M Bourns J.W. Miller 伯恩斯 | 当前型号 | 当前型号 |
MPLC0730L1R0 基美 | 功能相似 | SRP6540-1R0M和MPLC0730L1R0的区别 |
MPLCG0630L1R0 基美 | 功能相似 | SRP6540-1R0M和MPLCG0630L1R0的区别 |
HM72B-061R0LFTR13 TT Electronics/BI | 功能相似 | SRP6540-1R0M和HM72B-061R0LFTR13的区别 |
