SRR1206-270ML

屏蔽式高功率电感器 Shielded High Power Inductors

屏蔽 绕线 器 68 毫欧最大 非标准

得捷:
FIXED IND 27UH 2A 68 MOHM SMD

立创商城:
27uH ±20% 2A 68mΩ

贸泽:
固定电感器 27uH 20% SMD

艾睿:
Use this power SRR1206-270ML surface mount inductor from Bourns to make any circuit look clean and compact. This SMD inductor has an operating temperature range of -40 °C to 125 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 10M Hz. It has an inductance of 27u H. This device utilizes wirewound technology. It has a tolerance of 20%. This product is 13 mm long, 6.5 mm tall and 13 mm deep. This SMD inductor has a maximum DC current of 2 A with a maximum resistance of 68m Ohm.

安富利:
Ind Power Shielded Wirewound 27uH 20% 1KHz 21Q-Factor Ferrite 2A T/R

Chip1Stop:
Inductor Power Shielded Wirewound 27uH 20% 1KHz 21Q-Factor Ferrite 2A 68mOhm DCR T/R

Verical:
Inductor Power Shielded Wirewound 27uH 20% 1KHz 21Q-Factor Ferrite 2A 0.068Ohm DCR T/R

Online Components:
Inductor Power Shielded Wirewound 27uH 20% 1KHz 21Q-Factor Ferrite 2A 68mOhm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 27uH 20% 1KHz 21Q-Factor Ferrite 2A 68mOhm DCR T/R
